Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 158
Fig. 65. Worm. Fig. 66. Clutch and Worm Gear. knitting machines. Four legs support the annular base frame A,which is machined to guide the take-up plate B, and connected bythe take-up standards C C to the rotating bevel gear ring D (See A,in Fig. 58). This is seated in the stationary bedplate or…
Textile fabrics · Textile industry
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
