Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 291

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 291
vement, so that the lever is retained by the spring-latch and the 257 240 KNITTING driving-belt held on the loose pulley, thus stopping the machine. Tostart the machine, lift the spring-latch and permit the spring to causethe belt-shipping lever to restore the belt to the fast pulley; the move-ment… … Fig. 151. ley, but not to be engaged by the spring-latch, so that the power isthrown off the machine momentarily, at the moment when the changein the knitting above described is taking place. The cam-liigs operatethe lever and pass beyond it during the time that the pawl is makingone stroke to…

Textile fabrics · Textile industry

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
