Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 295

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 295
eel, and lowers theneedles to position for circular work. A pin 98 projects from the cam90, and is engaged by the outer end of a spring 99, the other end ofwhich is secured to the flange of the cam-web 82. The spring acts todepress the block and cams when permitted by the descent of plate… … Fig. 155. or is given a rotary reciprocating motion to produce heel-and-toe work.While doing the latter, practically one-half of the needles are firstthrown out of action; and a portion of the remaining needles are then thrown out of action one by one to nar-row, being restored in the reverse…

Textile fabrics · Textile industry
