Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)
Chicago : American school of correspondence · leaf 126
Fig. 41 shaft bracket bearing is a hand wheel J, for turning the machine byhand when occasion requires. Attached to the shaft arm is a beltshipper with belt and handle. On the shaft, inside the housing, isa bevel pinion K, which, meshing into the needle cylinder gear L,rotates the cylinder. Ill… … Needle Cylinder. (Fig. 40).The cylinder needles are re-ciprocated vertically in slots inthe periphery of the needle cylin-ders, as shown in the illustra-tion. Needle cylinders are us-ually constructed from steelforgings of good quality, as therequirements are very severe;the needle walls or lands…
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
