Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 131

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 131
Fig. 46. Dial Needle Cams. The several screws, heads and holes show the means employed tosecure the cams on the reverse side. The cap is fastened to the dialshaft G by means of set screws througli the hub F. Automatic Knitting Mechanism. On the automatic machine,the work cams are connected by a…

Textile industry · Textile fabrics

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
