Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 134

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 134
his. They can be attached to the rods P^and made to increase the tension on the fabric, or turned aroundand attached to the take-up blocks directly, and adjusted to diminishthe tension. Bobbin Rack. Fig. 50 represents the bobbin rack. H is acasting with a hub, in the bore of which is held, by means… … 190 KNITTING 107 with the hub, and outside these another circle of the same number aresimilarly arranged. The bobbins are placed on these pins. On theupper end of the rod H is fastened a hub H* in which are drilled asmany radial holes as there are bobbin pins, and extending from each ofthese holes…

Textile industry · Textile fabrics
