Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 140

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 140
ood, and is described as follows: Asthe needles advance on the rise cams, the loops in the hooks openthe latches, slipping over them into the throats, and the cylinderneedles, on striking the stitch cams, take the thread from the threadguide. On drawing the needles back, the loops in the throats… … Fig. 53. Yarn Guide or Carrier 124 KNITTING 111 This method of stitch forming is shown in the diagrams I, XL, III.,and IV. in Figs. 55 and 55; C representing a section of the cylinderand G a section of the (Hal, each with needles in about their relative DIAL needle: LATCH /-^^BUTT HOOK

Textile industry · Textile fabrics
