Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 65

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 65
8. At the inner end shaft 5, holds the presser wheelstud 13, with set screw 9. This stud is adjustable up and downand on it runs the presser wheel. Inside Circles. Inside the cylinder and above it is the insideplate or ring, supported by four ribbed arms 1, Fig. 22, and secured 54 KNITTING. 43 to… … Fig. 21. Presser Stand Assembled and Parts. When the screw is loosened the gripe may be moved circumfer-entially to any position without otherwise altering the position ofthe bur. The bur arm 11, may be rotated by loosening set screw 55 44 KNITTIKG. 5 and allowing the holder 6, to be moved as…

Textile industry · Textile fabrics
