Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School of Correspondence · Chicago, American School of Correspondence · leaf 346

An illustration from Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 346
e reversion of all the necessaryparts from the position, occupied during the outward run, to the posi- 270 COTTON SPINNING tion which they are obliged to assume during winding. The mechan-ism is shown in Figs. 224, 225 and 226. At the end of the outward run, the carriage shaft clutch, H, isthrown… … Pig. 224. Detail of Cam Shaft. spinning. This unwinds the few coils of yarn that are around thespindle between the top of the cop and the point of the spindle. Thewinding faller, K-, which acts as a guide for the yarn, is brought downinto position and the counterfaller, K^, ascends, until it meets…
