Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 218
187 178 TEXTILE CHEMISTEY AND DYEING they are swung up into the position indicated by the dotted linesafter the dyeing, etc., have been completed, leaving the hydro-extractor free to rotate. These two pipes are connected by athree-way cock A which controls the direction of flow of the dyeliquor and… … Fig. 69. Sectional View of Jig Dyeing MacMne. have its flow reversed, entering at I and leaving at k. The liquidthen flows through the material from the outside. By this two-fold direction of flow more uniform results in the dyeing are ob-tained. The dyeing being completed, the outlet valves m are…
Textile fabrics · Textile industry
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
