187 178 TEXTILE CHEMISTRY AND DYEING they are swung up into the position indicated by the dotted linesafter the dyeing, etc., have been completed, leaving the hydro-extractor free to rotate. These two pipes are connected by athree-way cock li which controls the direction of flow of the dyeliquor… … Pig. 69. Sectional View of Jig Dyeing Machine. have its flow reversed, entering at / and leaving at /.. The liquidthen flows through the material from the outside. By this two-fold direction of flow more uniform results in the dyeing are ob-tained. The dyeing being completed, the outlet valves m…
