e Kiel, Figs. 73 64 TEXTILE CHEMISTRY AND DYEING. 34 and 35 serving as an example. In this form of kier the topmay l)e closed tight and the boiling done under a slight pressure,say of 5 to 10 lbs., or a vent pipe is sometimes introduced in thetop which allo^vs the boiling to take place at… … Fig. 31 A. Cross Section of Fio-. 31. che liquor which is constantly flowing from the bottom of the kierinto tlie injector througli the pipe A. Through the valve E, thecontents of the kier may be discharged after the boiling. The gain in economy of tliis kier was slight, but neverthelessmany of the…
