Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 196

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 196
ce under each bed,or four times in passing through the machine. In Fig. 66 theconstruction of the beds is illustrated more fully. A radicaldeparture has been made at this point by having the pressure fromthe truss rod applied at the quarters instead of in the center ofthe bed as is the general… … aO A 168 162 WOOLEN AND WORSTED FINISHING ment is easily made. When adjusted this bed is sure to maintainits straightness under any conditions of pressure, and heat, andthe cloth will be pressed uniformly the whole width. The cylin-der head is bolted in, and the fact that it is built in this…

Textile industry · Textile fabrics

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
