aquarter-inch scale. Draw A B, Jig. 1, equal 3 feet, raise A g perpen-dicular to A B, and equal to a b ; draw b h paralleland equal to Ag; join </ fe, draw b c in any oblique Fig. 1. X /^ dJ—- / K direction toward the right; make b c equal a b,draw he, ad, and gf, all parallel and equal tob c ;… … make A d equal to A b, draw b c, ef, and dg, allparallel and equal to a d, join d c, Df,fg, andg c, and the cube is constructed as required.(To he continued.) Western Literary Institution—Among otherlectures given here to illustrate new manufactures,in addition to those on stock subjects, have…
