ired. 50. Case 1. When like traces of thegiven planes may be made to intersect, noauxiliary plane is required for the solution ofthe problem. Method. 1. Determine the points of in- tersection of like traces of the planes, whichpoints are the traces of the line of intersectionbetween the planes. 2.… … Fig. 84. Fig. 85. 36 DESCRIPTIVE GEOMETRY Figs. 86 and 87 illustrate a special condi-tion of Case 1, in which one of the planes isparallel to a coordinate plane. Plane iV isinclined to both Fand H^ and plane R is par-allel to H. Since plane R is perpendicular toFi its vertical trace will be the…
