The design and construction of oil engines; (1900)
Goldingham, Arthur Hugh. [from old catalog] · New York, Spon & Chamberlain; [etc., etc.] · leaf 134
d dynamo is usuallyflexible to allow of dynamo bearings and the engine-shaft bearings remaining in alignment when they be-come worn. In direct-connected plants the loss due tothe belt transmission is avoided, and a saving is thuseffected; but, on the other hand, the first cost of thedynamo is very… … OIL ENGINES DRIVING DYNAMOS. 119 two-cylinder vertical type, coupled direct to the shaft ofthe dynamo, all placed on one bed-plate. The cranks of the engine are placed in line, and ac-cordingly an impulse at each revolution of the crank-shaft is obtained. The method of working and the de-tails of…
Internal combustion engines
