Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 30
om the point of explosion to the exhaust Theaverage pressure or mean effective pressure as it is called iscomputed from the indicator diagram by dividing it into a num-ber of equal parts along the horizontal line, adding the lengthsof the pressure lines such as CH, CF, etc., and dividing the… … Fairbanks-Morse Gasoline Pumping Engine. Pump is Gear Driven Fromthe Engine Crank-Shaft at Reduced Speed. Knowing the mean effective pressure, the total pressure onthe piston, or the force is found by multiplying the area of thepiston in square inches by the average pressure per square inch.This…
Internal combustion engines · Traction-engines
