The design and construction of oil engines (1910)

Goldingham, Arthur Hugh. [from old catalog] · New York, Spon & Chamberlain; [etc., etc.] · leaf 278

An illustration from The design and construction of oil engines, 1910, leaf 278
heel exceeds the normalnumber of revolutions for which the engine is set, thegovernor mechanism opens the by-pass oil-valve, allow-ing part of the oil to flow back to the oil-tank, and ac-cordingly reduces the charge entering the vaporizer,and consequently the mean pressure for one or…

Internal combustion engines
