o horizontal cylindrical boilers, of the followingproportions : Total area of grate surface, 66 sq. ft. Total heating surface, (about) 2,866 684 PUMPS, RECIPROCATING. SQ ft Total are^ of cross-section of tubes, 7-18 sq. ft. Total area of chimney flue, 8-33so ft Ratio of heating surface to grate… … pressure in boilers, per gauge, 81-05 lbs. Mean steam pressure at engine, per gauge, 78-01lbs Mean steam pressure in jackets, per gauge, 70-075 lbs. Mean water pressure, pergauge, 99-565 lbs. Total mean pressure on pumps, corrected, 103-735 lbs. Mean vacuum,per gauge on condenser, 28-9 in. Mean…
