Goldingham, Arthur Hugh. [from old catalog] · New York, Spon & Chamberlain; [etc., etc.] · leaf 282
VARIOUS ENGINES DESCRIBED. 183 valves are actuated from the cam-shaft, these valves … Fig. 77a. being placed on the side of the engine. The air inletin this type is different from the other engines de- 184 OIL ENGINES. scribed. In this case the air enters not through the va*porizer, but by means of separate valve-chamber.
Internal combustion engines
