temperature maybe found on the thermometer scale: those for pressure, by theindicator gauge. In practice, however, it is. customary to use ab- PRESSURE, TEMPERATURE AND VOLUME. 183 solute figures, as they are called, which represent the sum of thethermometric or the gauge figures with certain… … Fig. 141.—A Daimler Single-Cyimtler Motor intended for Stationary Use. Attached tothe head of the water-cooled cylinder are the gasoline chamber and carburetter.The lubricating cup is shown immediately below. The exhaust valve, not shown, isoperated by a cam on the secondary shaft, geared to the…
