Goldingham, Arthur Hugh. [from old catalog] · New York, Spon & Chamberlain; [etc., etc.] · leaf 307
from the cam-shaft, and afterpassing through the cylinder and taking up the heatis delivered to the upper part of this chamber and flowsdown a wooden gradirwork. A draft of air is at thesame time induced by the exhaust emitted above, which 202 OIL ENGINES. rapidly cools the water as it trickles… … Fig. 90. draft of air is induced in the same way as above men-tioned. An engine equipped with this cooling device isshown in Fig. 90, as made by Grossley Bros., Man-chester, England. Another type of portable engine is that shown inFig. 91, consisting of the Mietz & Weiss engine. This 1ORTABLE…
Internal combustion engines
