Noyes, William, 1862-1928 · Peoria, Ill. : Manual Arts Press · leaf 52
Fig. 40. Cross-cleats for scrap-basket. one of the cross-cleats in the trough of the miter-box, edge up, andwith the back-saw slid into one of the 45° kerfs, cut off the cleat 52 DESIGN AND CONSTRUCTION IN WOOD … Fig. 41. Triraniingf a miter. near the end. Do this for all 4 cleats. Now measure accuratelythe length (7% outside length), put the saw in the other 45° kerfand saw off the other ends. Each cleat will now be of the shape shown in Fig. 40. Test eachcleat to see that the end is squarewith the edge,…
Woodwork
