pping Legs. Finishing WOODWORK FOR THE GRADES 135 LESSON 38 ASSEMBLING TABORET After all the parts are ready to put together, set the legson end in the position in which they will be when nailed inplace, and mark an X at each side where a nail is to be driveninto the side of a leg to secure the leg… … Fig. 186—Drilling Holes for Nails the thickness of a rail, and draw a light pencil gauge line oneach outside surface, (the surface opposite the face-marks)of each leg at the top end. You will notice that these linesare not on surfaces which have face-marks. Lay the legs side by side with their top…
