The design of marine engines and auxiliaries (1916)
Bragg, Edward Milton, b. 1874 · New York, D. Van Nostrand Co. · leaf 119
of the ends of the connecting rod and also the acceleration of itscenter of gravity. Where the acceleration of all three points isthe same the rod has a motion of translation and the acceleratingforce is applied at the center of gravity of the rod. This occursat crank angles of 45° and 135°. When… … Figs, so, 51. ENGINE BALANCING 105 of gravity of the rod is zero and when, consequently, the acceler-ating force is zero, the point of application is at infinity. Thusthe maximum deviation from the assumed condition occurs at atime when the force itself is a minimum. The deviation of theassumed…
Marine engines
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
