The design of marine engines and auxiliaries (1916)
Bragg, Edward Milton, b. 1874 · New York, D. Van Nostrand Co. · leaf 181
Fig. 91. water accumulates. In the Edwards pump the flow of waterdoes not depend upon the pressure difference but the water iscaught between the under side of the bucket and the bottom … Fig. 92. end of the pump and forced onto the top of the bucket. In Fig.76 is shown a double-acting pump of class (2). Fig. 92 shows aset of cards taken from this pump. In the top card we see the CONDENSERS AND AIR PUMPS 163 sudden increase in pressure when the water passes through thetop valves. On…
Marine engines
