Design of a steel highway bridge (1913)

Reed, Erwin Ambrose · leaf 56

An illustration from Design of a steel highway bridge, 1913, leaf 56
. This gives ar.iple clearance for two [laps-ing teams or automobiles. It was deemed best not to cut down on the water-v/ay. Al-though the channel is small during ordinary stages of flow, thewidth becomes considerable when the floods raise the level to with-in two feet of the floor of the bridge.…

Bridges · Iron and steel bridges · Theses

Internet Archive · University of Illinois Urbana-Champaign · Public Domain Mark 1.0. Free to use for anything.
