be made of one v.-hole plate because it iscontrolled by the market size of the material. It is found to bemost economical in material to splice the web in two sections asshown in detail drawing Plate XII. In designing the v/eb splice, thenumber of rivets should be sufficient to tranBm.it the total… … 20 The thickness of the splice plate shall be the same as that of theweb. The thicknesses of the web are determined as shown in Table II Art, 12. Rivet Spacings The rivet spacing is determined by the formula P V where p = the spsicing in inches, V = the bearing or shearing value of one rivet. From…
