meter, and they must be 3! ins. apart, center tocenter, and equidistant from the center of the armature chamber; if themagnet limbs conform strictly to the measurement given from face toface of the finished part of the limbs, the centers of the holes, h, h, willeach be 3-16 in. from the joint… … FIG. 2 magnet and the journal yokes, F, F, shows the function of these rods;they support the yokes and carry distance-pieces, c, c, d, d, made of brasstubing just large enough to slip over the rods, and having J-in. walls.The pieces, c, c, are if ins. long, and d, d, are 2\ ins. long. The yokesare…
