he extentto which pipe can be bent by machinery, and are used largely for heaters andin refrigerating plants. 404 MACHINE DESIGN AND MECHANICAL CONSTRUCTIONS. FIG. 960. Figs. 963 and 964 are a tee and a cross, as used in connections of hydraulicpresses, made of composition. The tubes are of… … FIG. 965. FIG. 966. FKI. In Lelands lead-pipe coupling (Figs. 965 and 966) a double-cone ring isinserted between the ends of the pipes to be coupled, and they are brought to-
