A dictionary of architecture and building; biographical, historical and descriptive (1901)
Sturgis, Russell, 1836-1909 · New York, Macmillan · leaf 568
(&) With groin ribs and transverse arches(Fig. 50). From Gerland, France; one of theearliest examples. Both ril)s and arches aresemicirciUar, and the vaulting is therefore domi-cal. (c) Groin and wall ribs only (Fig. 51). (d) Groin, transverse, and wall i-ibs, withlevel ridges (Fig. 52). The… … 6 (Plan). with may stop at the crossing and be connectedthe centre by a single licrne (Fig. 55). (/) Groin, transverse, intermediate, andridge ribs (Fig. 44). (g) Side vaults oblique (Fig. 56), choir ofLincoln cathedral. The half groin ribs on962 ^^ // \v^\
Architecture
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
