its function fulfilled by a weigiit at the feet of the rafters. To go a comparedhas been … ARCH ure at each of its oblique ends, while the com-bination of all these six pressures results in alateral push on eacli abutment as shown by thearrows. This lateral push, in Figs. 2 and 3, issimilar to that in Fig. 1, from whichit diflers in direction, owing to theinclination of the end jncccs ;…
