A dictionary of architecture and building : biographical, historical, and descriptive (1902)
Sturgis, Russell, 1836-1909 · New York : The Macmillan company · leaf 561
Fig. 47. the plan. Its curve is ellijjtical if the compos-ing vaidts are conical ; otherwise it is indefin-able (Figs. 15, 16, 17). (c) The so-called cloistered arch, or squaredome (Fig. 18), is composed of four parts of … Fig. 48 (Plan and Section). equal baiTel vaults, but is just the reverse of the groined, the internal angles being reentrant. (d) A square space at the corner of a cloister is often covered by two intersecting barrel
