A dictionary of electrical words, terms and phrases (1898)
Houston, Edwin J. (Edwin James), 1847-1914 · New York, The W. J. Johnston company · leaf 124
Fig. 157. Two-partCommutator. Fig. 158. Two-partCommutator. segments are, therefore, made of comparativelythick pieces of metal, insulated from one another, Com.] 114 [Conu … and supported on a commutator cylinder usuallyplaced on the shaft of the armature. The ends of the armature coils are connectedto commutator strips or segments. The number of metallic pieces or segments, A. and A, on the cotnmutator cylinder depends on the number, arrangement and connection of the…
Electricity · Electrical engineering
