Key, Reversing A key inserted in the circuit of a galvanometer for obtainingdeflections of the needle on either side of thegalvanometer scale. A form of reversing key is shown in Fig. 328.The galvanometer terminals are connected to thebinding posts 2 and 3, and the circuit terminalsto the other two… … Fig: 328. Reversing Key. current flows m one direction and on depressingK, it flows in the opposite direction. Clamps,operated by handles, are provided so as to closeeither of the keys permanently, if so desired. Key, Reversing, of Quadruplex Tele-graphic System A key employed to reverse the…
