A dictionary of electrical words, terms and phrases (1896)
Houston, Edwin J. (Edwin James), 1847-1914 · New York, The W.J. Johnston company · leaf 342
ynamo-electric machine is shown in Fig. 353. This ma-chine is designed to maintain constant potentialat its terminals. There are two varieties of series and shunt-wound dynamos, viz.: (1.) Long-shunt compound-wound dynamo. (2.) Short-shunt compound-wound dynamo. (See Machine, Dynamo-Electric,… … D D D D Fig. 354. Series Dynamo. connected in series with the armature circuit,so that the entire armature current must passthrough the field coils. A series dynamo-electric machine is shown inFig. 354. Here the armature circuit, the fieldcircuit and the external circuit are all connectedin series.…
Electricity · Electrical engineering
