The electric motor and the transmission of power (1906)
Houston, Edwin J. (Edwin James), 1847-1914, Kennelly, Arthur E. (Arthur Edwin), 1861-1939, joint author · New York : McGraw Pub. Co. · leaf 332
e circuits is from2,000 to 2,400 volts, according to require-ments. The two generators are indicatedat 1 and 2. Their four wires are led toseparate switches ^Sand S\ Each switchis arrano^ed so that it can either be discon-nected altogether, as shown in the diagram,or can make connection between the… … Fig. 99.—Diagram Showing the Connections ofTHE Generators with Local and Long DistanceFeeders. if it be thrown on the other side, it willconnect the generator wires to the fourbus-bar wires £, THE TRANSMISSION OF POAYER. 325 The two sets of bus-bars are arranged soas to enable the two separate…
Electric motors
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
