s … Fig. \ob.—Joys Valve Gear. (not here shown), jointed to the connecting-rod (K, Fig. 9) in such a.manner that the rod D E is compelled to follow the movement of theconnecting-rod, but the end E must always travel in the circular segment.We have hitherto supposed this segmental piece to be fixed, but…
