Draw frames and fly frames : being a practical treatise on the above machines (1898)
Thornley, T. (Thomas) · Manchester : A. Heywood · leaf 12
onnections ... 67 Chapter V.Fly Frames—Building Motion 116 Chapter VI.Fly Frames —Changing from Twist Way to Weft Way, &c. ... ... „.. 167 Chapter VII.Fly Frames—How to Put Up ... ... ... ... 195 Chapter VIII.Fly Frames—New Differential Motions... ... ... 219 Chapter IX.Roller Setting and… … In Fig. I is given the plan of a type of drawing framewhich about 1830 had been in use a good number of years.At A are shown the fast and loose pulleys. From A thewheels B gave motion to the delivery roller. The machinecontained four pairs of drawing rollers, as is yet thepractice. It contained,…
Textile machinery
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
