x of the largest Edison dynamos. 202 THE ELECTEIG LIGHT. This generator (Fig. 109) is of the Edison horizontal type, themagnetic field being prod need by a battery of twelve horizontalelectro-magnets disposed in three rows of four magnets each,two rows being attached by their ends to the upper… … Fig. 108. within a cylindrical space bored out of the verv massive pole-pieces shown in the front of the illustration, and which are builtup of twelve heavy blocks of cast iron, held together by longbolts threaded through them, and by surface coupling platesscrewed on to three of their faces. The…
