rrent in the conductors. This mutual actioncontinues until the magnetic limit of the soft iron of the electro-magnets is attained. The maximum inductive effect upon eachconvolution of the rotating coils occurs when it passes throughthe centre of the two magnetic fields; that is, approximatelywhen… … Fig. 369. Fig. 868 shows the arrangement of the wires in this machine.The continuous current produced by the armature A traversesthe two field magnets or inductors I and I, at the same time thatit traverses and feeds the arc which forms a part of the circuit. AT.TENEOK S DBUM ARMATURE MACHINE. 571…
