Dynamo-electricity: its generation, application, transmission, storage and measurement (1884)
Prescott, George B. (George Bartlett), 1830-1894 · New York, D. Appleton · leaf 625
icity; and the following sketches illus-trate some of the various arrangements proposed by the inven-tor: Fig. 895 is a diagram showing a simple form of machine ;A bobbin, A, having cheeks or flanges, A B, of soft iron, andwound with a coil of insulated wire, is fixed obliquely on an 604 THE… … Fig. 395. N and S, and alternating electric currents are set up in the coilof A. Fig. 896 shows a construction in which the bobbin B,fixed obliquely on the axis O, revolves within an oblique bob-bin, C, which has an iron sheath, F, presenting interior polaredges toward the edges of B. The electric…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
