Dynamo-electricity: its generation, application, transmission, storage and measurement (1884)
Prescott, George B. (George Bartlett), 1830-1894 · New York, D. Appleton · leaf 778
his type is made upof twelve cells and weighs 84 lbs. Mr. de Kabath has recentlygiven up these forms in favor of an open trough type, which KABATH S ACCUMULATOR. 757 are contained in rectangular wooden boxes, lined inside withhard rubber, separated from the wood bj a thin coat of insulatingmastic… … This latter detail is advantageously replaced by glass plates,having the same height as the box, and provided with twogrooves. These plates are placed at opposite ends of the box,and receive two cells, forming a couple. Fig. 495 shows such acouple between the two glass guides, the box of course not…
Electrical engineering
