Dynamo electric machinery; its design, construction, and operation; direct-current machines (1915)
Sheldon, Samuel, 1862-1920, Hausmann, Erich, 1886- joint author · New York, D. Van Nostrand Company; · leaf 191
Fig. 104. Fig. 104 shows a 350-K.W. engine-type generator madeby the Westinghouse Electric and Manufacturing Company. GENERATORS. 179 Some of the important features of this design are the useof conductor retaining wedges in the armature slots, thearrangement of the series field coil connections,… … Fig, 105. Fig. 105 depicts a General Electric Company generatordirect coupled to a steam turbine, and mounted on a com-mon bedplate. The cut shows the generating unit assemitransparent so as to reveal the interior parts. The field-magnet frame of a 6-pole single-coil type ofLundell generator with…
Electric machinery
