or arm and of thebrush holder is obtained bymeans of a small motorwhose field is sneaked from the main magnets of themachine. This motor is operated by a device shownin Fig. 121. The whole device is inserted in series withone of the mains from the generator. The right-handlever is of insulating… … Fig. 120. GENERATORS. 199 The magnet and spring are so adjusted that when the nor-mal current is flowing, both a and b are in contact with theleft lever, and the current flows in the three shunt paths,R, R^, and R^. There will be no current in the armatureof the regulating motor, since the…
