Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 56

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 56
of belt in feet per 2 cosine X )minute = foot-pounds, which divided by 33,000 = H. P. B, long arm;A, short arm of lever. MEASUREMENT OF POWER. 49 144. NEERS ROTARYTRANSMITTING DYNAMO-METER.—A shaft is disconnectedat a coupling and the discs A andB are clamped one to each shaft.Chains are attached…
