ent. As there is no iron inthe magnetic circuit and since the speed of rotation is low,little or no counter E.M.F. will be induced in the armaturecoil; thus the armature current is independent of the speed,and is directly proportional to the line voltage. For thesame reason the field flux is… … Fig. 203. CENTRAL-STATION EQUIPMENT. 311 speed of rotation proportional to the torque. This is accom-plished by applying a magnetic drag, in the form of analuminum disk fastened to the armature spindle and passingbetween the poles of permanent magnets. The electromo-tive forces induced in the disk…
