Dynamo electric machinery; its design, construction, and operation; direct-current machines (1915)
Sheldon, Samuel, 1862-1920, Hausmann, Erich, 1886- joint author · New York, D. Van Nostrand Company; · leaf 70
Fig. 26. it is seen that connection is made to inductor No. 10,which is connected at the rear to inductor No. 19; and ARMATURES. 59 this at the front is joined to segment / and also to inductorNo. 28. Proceeding in this way, the winding scheme maybe tabulated as follows : REAR END FRONT END to to…
