uplex wind-ing may be either singly or doubly re-entrant, a triplexwinding may be either singly or triply re-entrant, and aquadruplex winding maybe singly, doubly, or quad-ruply re-entrant. Multi-plex windings beyondthese are rarely used inpractice. The general formula formultiplex wave windings is… … ARMATURES. 65 mean winding pitch, and therefore also the total numberof inductors, depends upon the degree of re-entrancydesired. The highest common factor of X and _y expressesthe degree of re-entrancy. Thus, for the duplex windingof Fig. 31, y ^ 2 and ^ = 9) therefore the winding must be singly…
