what is called a (/Is-cJiargc resistance to pi event excessive sparking and possible dam-age to the insulation of the field windings when the field circuitis opened. This discharge resistance is a moderately high re- SWITCHBOARDS AND SWITCHBOARD APPLIANCES. 395 sistance which is connected across… … ing of the switch. A rheostat is shown in the field circuit of thegenerator and another rheostat is shown in the field circuit of theexciter in Fig. 285. The armature terminals of the three-phase 396 DYNAMOS AND MOTORS. generator in Fig. 285 are connected through the three ammetersand through a…
